Parameter (X axis): θ(π+), deg
You are not logged in.
Experiment: E1-6, 2025, 2001
Spokespersons: R.W. Gothe, A. Trivedi
Experiment comment: Experiment year: 2001—2002
No publications available for this experiment
Quantity measured: dσ/d(−cos(θ(π+))), mcb/rad
Differential cross section, where cos(θ(π+) is cosine of the azimuthal angle of π+ in CMS.
Beam: e, polarization: none
Target: p (Z=1, A=1), polarization: none
Final state: π+π−p, polarization: none
| Q2 : | 3.5 — 4.2 GeV2 | |
|---|---|---|
| W : | 2 — 2.025 GeV | |
| Ebeam : | 5.754 GeV |
|
Observable quantity measured (Y axis): dσ/d(−cos(θ(π+))), mcb/rad
Parameter (X axis): θ(π+), deg |
Click here to get data in text file, delimited with tabs.
Measured data:
|
θ(π+),
deg |
dσ/d(−cos(θ(π+))),
mcb/rad |
Stat. error,
mcb/rad |
Syst. error,
mcb/rad |
Total error,
mcb/rad |
|---|---|---|---|---|
| 9 | 1.8646 | 0.1396 | 0.2344 | 0.2728 |
| 27 | 1.6563 | 0.1458 | 0.2206 | 0.2645 |
| 45 | 1.0692 | 0.0727 | 0.2043 | 0.2169 |
| 63 | 1.0419 | 0.0736 | 0.1885 | 0.2024 |
| 81 | 1.0974 | 0.0662 | 0.173 | 0.1853 |
| 99 | 0.9755 | 0.0812 | 0.1557 | 0.1756 |
| 117 | 0.8009 | 0.0467 | 0.1322 | 0.1402 |
| 135 | 0.6214 | 0.0436 | 0.1211 | 0.1288 |
| 153 | 0.5638 | 0.0769 | 0.213 | 0.2264 |
| 171 | 0.9206 | 0.0029 | 0.5522 | 0.5522 |
