Measurement E11M10
| Experiment: | EG1 | |
|---|---|---|
| Year: | 2000 | |
| Spokespersons: | P. Stoler, V. Burkert, R. Minehart | |
| Reaction: | ep → π0p | |
| Polarization: | beam, target (longitudinal) | |
| Quantity: | Abt(θπ, φπ) | |
| Q2: | 0.379 — 0.54 GeV2 | |
| W: | 1.2 — 1.25 GeV | |
| Publication: |
under preparation //
|
|
| cos(θπ) | φπ, [deg] | Abt(θπ, φπ), [1/sr] | uncertainty |
|---|---|---|---|
| -0.929 | -162.0 | 1.05 | 0.362 |
| -0.786 | -162.0 | 0.434 | 0.181 |
| -0.643 | -162.0 | -0.107 | 0.151 |
| -0.5 | -162.0 | -0.501 | 0.168 |
| -0.357 | -162.0 | -0.583 | 0.201 |
| -0.214 | -162.0 | -0.474 | 0.126 |
| -0.071 | -162.0 | -0.611 | 0.128 |
| 0.071 | -162.0 | -0.554 | 0.104 |
| 0.214 | -162.0 | -0.684 | 0.116 |
| 0.357 | -162.0 | -0.683 | 0.104 |
| 0.5 | -162.0 | -0.575 | 0.109 |
| 0.643 | -162.0 | -0.598 | 0.122 |
| 0.786 | -162.0 | -0.308 | 0.112 |
| 0.929 | -162.0 | -0.074 | 0.103 |
| -0.929 | -126.0 | 0.415 | 0.154 |
| -0.786 | -126.0 | -0.156 | 0.142 |
| -0.643 | -126.0 | -0.087 | 0.116 |
| -0.5 | -126.0 | -0.197 | 0.084 |
| -0.357 | -126.0 | -0.299 | 0.076 |
| -0.214 | -126.0 | -0.213 | 0.062 |
| -0.071 | -126.0 | -0.286 | 0.06 |
| 0.071 | -126.0 | -0.266 | 0.065 |
| 0.214 | -126.0 | -0.387 | 0.064 |
| 0.357 | -126.0 | -0.319 | 0.065 |
| 0.5 | -126.0 | -0.333 | 0.067 |
| 0.643 | -126.0 | -0.344 | 0.073 |
| 0.786 | -126.0 | -0.135 | 0.073 |
| 0.929 | -126.0 | 0.074 | 0.092 |
| -0.929 | -90.0 | 0.037 | 0.113 |
| -0.786 | -90.0 | -0.161 | 0.109 |
| -0.643 | -90.0 | -0.098 | 0.075 |
| -0.5 | -90.0 | -0.148 | 0.07 |
| -0.357 | -90.0 | -0.336 | 0.06 |
| -0.214 | -90.0 | -0.266 | 0.055 |
| -0.071 | -90.0 | -0.372 | 0.056 |
| 0.071 | -90.0 | -0.244 | 0.059 |
| 0.214 | -90.0 | -0.255 | 0.057 |
| 0.357 | -90.0 | -0.308 | 0.061 |
| 0.5 | -90.0 | -0.308 | 0.059 |
| 0.643 | -90.0 | -0.107 | 0.073 |
| 0.786 | -90.0 | -0.142 | 0.086 |
| 0.929 | -90.0 | 0.334 | 0.137 |
| -0.929 | 90.0 | 0.387 | 0.154 |
| -0.786 | 90.0 | -0.095 | 0.093 |
| -0.643 | 90.0 | -0.195 | 0.068 |
| -0.5 | 90.0 | -0.285 | 0.07 |
| -0.357 | 90.0 | -0.205 | 0.062 |
| -0.214 | 90.0 | -0.346 | 0.06 |
| -0.071 | 90.0 | -0.249 | 0.056 |
| 0.071 | 90.0 | -0.269 | 0.056 |
| 0.214 | 90.0 | -0.246 | 0.058 |
| 0.357 | 90.0 | -0.229 | 0.06 |
| 0.5 | 90.0 | -0.104 | 0.06 |
| 0.643 | 90.0 | -0.135 | 0.071 |
| 0.786 | 90.0 | -0.159 | 0.099 |
| 0.929 | 90.0 | 0.399 | 0.139 |
| -0.929 | 126.0 | 0.308 | 0.13 |
| -0.786 | 126.0 | 0.205 | 0.113 |
| -0.643 | 126.0 | 0.084 | 0.088 |
| -0.5 | 126.0 | -0.272 | 0.079 |
| -0.357 | 126.0 | -0.336 | 0.074 |
| -0.214 | 126.0 | -0.207 | 0.072 |
| -0.071 | 126.0 | -0.214 | 0.069 |
| 0.071 | 126.0 | -0.319 | 0.075 |
| 0.214 | 126.0 | -0.331 | 0.069 |
| 0.357 | 126.0 | -0.344 | 0.07 |
| 0.5 | 126.0 | -0.33 | 0.067 |
| 0.643 | 126.0 | -0.295 | 0.074 |
| 0.786 | 126.0 | -0.128 | 0.095 |
| 0.929 | 126.0 | 0.074 | 0.138 |
| -0.929 | 162.0 | 0.715 | 0.308 |
| -0.786 | 162.0 | -0.111 | 0.204 |
| -0.643 | 162.0 | -0.252 | 0.154 |
| -0.5 | 162.0 | -0.623 | 0.206 |
| -0.357 | 162.0 | -0.515 | 0.15 |
| -0.214 | 162.0 | -0.419 | 0.114 |
| -0.071 | 162.0 | -0.629 | 0.141 |
| 0.071 | 162.0 | -0.696 | 0.116 |
| 0.214 | 162.0 | -0.645 | 0.107 |
| 0.357 | 162.0 | -0.754 | 0.132 |
| 0.5 | 162.0 | -0.592 | 0.116 |
| 0.643 | 162.0 | -0.312 | 0.112 |
| 0.786 | 162.0 | -0.469 | 0.132 |
| 0.929 | 162.0 | -0.143 | 0.133 |
Measurement comment:
