Measurement E14M147
| Experiment: | E99-107 CLAS experiment | |
|---|---|---|
| Year: | 2005 |
|
| Spokespersons: | V. D. Burkert, R. Minehart | |
| Reaction: | ep → π+n | |
| Polarization: | target | |
| Quantity: | dσ/dΩ | |
| Q2: | 4.16 GeV2 | |
| W: | 1.27 GeV | |
| Ebeam: | 5.754 GeV | |
| cos(θπ) | φ(π+), [degree] | dσ/dΩ, [μb/sr] | uncertainty |
|---|---|---|---|
| -0.7 | 187.5 | 0.06301 | 0.01987 |
| -0.7 | 202.5 | 0.04659 | 0.02008 |
| -0.7 | 217.5 | 0.04126 | 0.01512 |
| -0.7 | 232.5 | 0.06535 | 0.02828 |
| -0.7 | 247.5 | 0.1897 | 0.0829 |
| -0.7 | 262.5 | 0.06568 | 0.01816 |
| -0.7 | 277.5 | 0.06754 | 0.0202 |
| -0.7 | 292.5 | 0.117 | 0.04022 |
| -0.5 | 37.5 | 0.0859 | 0.04789 |
| -0.5 | 52.5 | 0.07327 | 0.02535 |
| -0.5 | 67.5 | 0.08664 | 0.0241 |
| -0.5 | 82.5 | 0.063 | 0.01696 |
| -0.5 | 97.5 | 0.19418 | 0.04703 |
| -0.5 | 112.5 | 0.08285 | 0.02203 |
| -0.5 | 127.5 | 0.19589 | 0.05411 |
| -0.5 | 142.5 | 0.07874 | 0.02576 |
| -0.5 | 157.5 | 0.19519 | 0.06134 |
| -0.5 | 172.5 | 0.178 | 0.05531 |
| -0.5 | 187.5 | 0.17882 | 0.05575 |
| -0.5 | 202.5 | 0.06079 | 0.01995 |
| -0.5 | 217.5 | 0.06913 | 0.02173 |
| -0.5 | 232.5 | 0.13831 | 0.04629 |
| -0.5 | 247.5 | 0.16686 | 0.04528 |
| -0.5 | 262.5 | 0.1925 | 0.0513 |
| -0.5 | 277.5 | 0.14978 | 0.03447 |
| -0.5 | 292.5 | 0.09779 | 0.02226 |
| -0.5 | 307.5 | 0.12811 | 0.05543 |
| -0.3 | 37.5 | 0.02044 | 0.05275 |
| -0.3 | 52.5 | 0.16718 | 0.05622 |
| -0.3 | 67.5 | 0.11304 | 0.02654 |
| -0.3 | 82.5 | 0.15082 | 0.03934 |
| -0.3 | 97.5 | 0.12994 | 0.02763 |
| -0.3 | 112.5 | 0.1263 | 0.02818 |
| -0.3 | 127.5 | 0.20745 | 0.04366 |
| -0.3 | 142.5 | 0.18972 | 0.04765 |
| -0.3 | 157.5 | 0.12349 | 0.03417 |
| -0.3 | 172.5 | 0.1862 | 0.03694 |
| -0.3 | 187.5 | 0.1671 | 0.04292 |
| -0.3 | 202.5 | 0.16193 | 0.04121 |
| -0.3 | 217.5 | 0.18228 | 0.04855 |
| -0.3 | 232.5 | 0.16467 | 0.03388 |
| -0.3 | 247.5 | 0.1924 | 0.04056 |
| -0.3 | 262.5 | 0.17675 | 0.04498 |
| -0.3 | 277.5 | 0.12626 | 0.02635 |
| -0.3 | 292.5 | 0.11304 | 0.0258 |
| -0.3 | 307.5 | 0.18326 | 0.05137 |
| -0.3 | 322.5 | 0.15098 | 0.06592 |
| -0.1 | 37.5 | 0.21709 | 0.10847 |
| -0.1 | 52.5 | 0.16345 | 0.04701 |
| -0.1 | 67.5 | 0.17111 | 0.04233 |
| -0.1 | 82.5 | 0.15473 | 0.03321 |
| -0.1 | 97.5 | 0.13498 | 0.03397 |
| -0.1 | 112.5 | 0.17013 | 0.03913 |
| -0.1 | 127.5 | 0.12041 | 0.03347 |
| -0.1 | 142.5 | 0.18242 | 0.03962 |
| -0.1 | 157.5 | 0.22692 | 0.05859 |
| -0.1 | 172.5 | 0.27371 | 0.05661 |
| -0.1 | 187.5 | 0.1874 | 0.03703 |
| -0.1 | 202.5 | 0.24613 | 0.05071 |
| -0.1 | 217.5 | 0.18891 | 0.03224 |
| -0.1 | 232.5 | 0.19521 | 0.04276 |
| -0.1 | 247.5 | 0.16013 | 0.03431 |
| -0.1 | 262.5 | 0.1037 | 0.02342 |
| -0.1 | 277.5 | 0.13156 | 0.03617 |
| -0.1 | 292.5 | 0.14197 | 0.03315 |
| -0.1 | 307.5 | 0.1996 | 0.05966 |
| 0.1 | 37.5 | 0.12907 | 0.05177 |
| 0.1 | 52.5 | 0.1205 | 0.04516 |
| 0.1 | 67.5 | 0.12645 | 0.03608 |
| 0.1 | 82.5 | 0.11249 | 0.02698 |
| 0.1 | 97.5 | 0.14703 | 0.02897 |
| 0.1 | 112.5 | 0.14432 | 0.02955 |
| 0.1 | 127.5 | 0.18846 | 0.03453 |
| 0.1 | 142.5 | 0.20644 | 0.04316 |
| 0.1 | 157.5 | 0.22037 | 0.04799 |
| 0.1 | 172.5 | 0.22799 | 0.0514 |
| 0.1 | 187.5 | 0.26815 | 0.04423 |
| 0.1 | 202.5 | 0.22037 | 0.0443 |
| 0.1 | 217.5 | 0.13987 | 0.02875 |
| 0.1 | 232.5 | 0.1212 | 0.02493 |
| 0.1 | 247.5 | 0.18105 | 0.03685 |
| 0.1 | 262.5 | 0.15916 | 0.03505 |
| 0.1 | 277.5 | 0.1367 | 0.03279 |
| 0.1 | 292.5 | 0.12645 | 0.04299 |
| 0.1 | 307.5 | 0.1205 | 0.03887 |
| 0.1 | 322.5 | 0.078 | 0.02891 |
| 0.3 | 7.5 | 0.10412 | 0.03289 |
| 0.3 | 22.5 | 0.1474 | 0.04497 |
| 0.3 | 37.5 | 0.11371 | 0.03373 |
| 0.3 | 52.5 | 0.13072 | 0.04399 |
| 0.3 | 67.5 | 0.14899 | 0.03182 |
| 0.3 | 82.5 | 0.17958 | 0.03456 |
| 0.3 | 97.5 | 0.19128 | 0.04017 |
| 0.3 | 112.5 | 0.15381 | 0.03488 |
| 0.3 | 127.5 | 0.18881 | 0.03854 |
| 0.3 | 142.5 | 0.20505 | 0.03642 |
| 0.3 | 157.5 | 0.25968 | 0.05417 |
| 0.3 | 172.5 | 0.26564 | 0.05008 |
| 0.3 | 187.5 | 0.29874 | 0.05282 |
| 0.3 | 202.5 | 0.20185 | 0.0344 |
| 0.3 | 217.5 | 0.27939 | 0.0547 |
| 0.3 | 232.5 | 0.24086 | 0.04854 |
| 0.3 | 247.5 | 0.21282 | 0.04548 |
| 0.3 | 262.5 | 0.19123 | 0.03509 |
| 0.3 | 277.5 | 0.11745 | 0.02455 |
| 0.3 | 292.5 | 0.14899 | 0.0424 |
| 0.3 | 307.5 | 0.13072 | 0.03929 |
| 0.3 | 322.5 | 0.11594 | 0.03334 |
| 0.3 | 352.5 | 0.07863 | 0.0239 |
| 0.5 | 7.5 | 0.1395 | 0.02559 |
| 0.5 | 22.5 | 0.11092 | 0.02428 |
| 0.5 | 37.5 | 0.15494 | 0.03405 |
| 0.5 | 52.5 | 0.13592 | 0.03626 |
| 0.5 | 67.5 | 0.19655 | 0.048 |
| 0.5 | 82.5 | 0.22038 | 0.06563 |
| 0.5 | 97.5 | 0.28544 | 0.05106 |
| 0.5 | 112.5 | 0.22795 | 0.03977 |
| 0.5 | 127.5 | 0.28063 | 0.05245 |
| 0.5 | 142.5 | 0.29655 | 0.05934 |
| 0.5 | 157.5 | 0.2686 | 0.04265 |
| 0.5 | 172.5 | 0.32731 | 0.06161 |
| 0.5 | 187.5 | 0.31055 | 0.05395 |
| 0.5 | 202.5 | 0.21369 | 0.03436 |
| 0.5 | 217.5 | 0.27271 | 0.04795 |
| 0.5 | 232.5 | 0.33006 | 0.06284 |
| 0.5 | 247.5 | 0.26434 | 0.0453 |
| 0.5 | 262.5 | 0.26739 | 0.05702 |
| 0.5 | 277.5 | 0.2249 | 0.04666 |
| 0.5 | 292.5 | 0.19655 | 0.05286 |
| 0.5 | 307.5 | 0.15524 | 0.04636 |
| 0.5 | 322.5 | 0.1513 | 0.045 |
| 0.5 | 337.5 | 0.14655 | 0.03814 |
| 0.5 | 352.5 | 0.1395 | 0.02835 |
| 0.7 | 7.5 | 0.10303 | 0.01662 |
| 0.7 | 22.5 | 0.13454 | 0.02486 |
| 0.7 | 37.5 | 0.15691 | 0.02956 |
| 0.7 | 52.5 | 0.18584 | 0.03633 |
| 0.7 | 67.5 | 0.21262 | 0.04239 |
| 0.7 | 82.5 | 0.29126 | 0.05473 |
| 0.7 | 97.5 | 0.18172 | 0.03463 |
| 0.7 | 112.5 | 0.28981 | 0.05074 |
| 0.7 | 127.5 | 0.2841 | 0.04415 |
| 0.7 | 142.5 | 0.23131 | 0.037 |
| 0.7 | 157.5 | 0.30437 | 0.05628 |
| 0.7 | 172.5 | 0.36078 | 0.05779 |
| 0.7 | 187.5 | 0.30658 | 0.04664 |
| 0.7 | 202.5 | 0.29086 | 0.04778 |
| 0.7 | 217.5 | 0.28768 | 0.04965 |
| 0.7 | 232.5 | 0.22671 | 0.03937 |
| 0.7 | 247.5 | 0.30507 | 0.05212 |
| 0.7 | 262.5 | 0.26883 | 0.05326 |
| 0.7 | 277.5 | 0.22946 | 0.05108 |
| 0.7 | 292.5 | 0.21305 | 0.04648 |
| 0.7 | 307.5 | 0.14032 | 0.02946 |
| 0.7 | 322.5 | 0.15691 | 0.03014 |
| 0.7 | 337.5 | 0.14523 | 0.02616 |
| 0.7 | 352.5 | 0.18721 | 0.02764 |
| 0.9 | 7.5 | 0.14636 | 0.0215 |
| 0.9 | 22.5 | 0.19567 | 0.03193 |
| 0.9 | 37.5 | 0.1391 | 0.02407 |
| 0.9 | 52.5 | 0.22048 | 0.03812 |
| 0.9 | 67.5 | 0.20404 | 0.03183 |
| 0.9 | 82.5 | 0.22717 | 0.0326 |
| 0.9 | 97.5 | 0.2876 | 0.04242 |
| 0.9 | 112.5 | 0.30654 | 0.04838 |
| 0.9 | 127.5 | 0.22956 | 0.03488 |
| 0.9 | 142.5 | 0.29595 | 0.04167 |
| 0.9 | 157.5 | 0.21136 | 0.03202 |
| 0.9 | 172.5 | 0.26877 | 0.03994 |
| 0.9 | 187.5 | 0.2654 | 0.03882 |
| 0.9 | 202.5 | 0.26591 | 0.03707 |
| 0.9 | 217.5 | 0.31907 | 0.04909 |
| 0.9 | 232.5 | 0.22733 | 0.03787 |
| 0.9 | 247.5 | 0.29775 | 0.05134 |
| 0.9 | 262.5 | 0.29758 | 0.04913 |
| 0.9 | 277.5 | 0.26066 | 0.04294 |
| 0.9 | 292.5 | 0.25626 | 0.03801 |
| 0.9 | 307.5 | 0.18078 | 0.02523 |
| 0.9 | 322.5 | 0.16275 | 0.0254 |
| 0.9 | 337.5 | 0.16547 | 0.02507 |
| 0.9 | 352.5 | 0.17248 | 0.02622 |
