Measurement E151M1593

Experiment: EG4
Year: 2016

Experiment comment:

Final asymmetry results for the ep-> e pi+ (n) channel extracted from CLAS/EG4 data obtained using a longitudinally polarized beam and a longitudinally polarized NH3 target (CAA HS07-02).
Spokesperson: Xiaochao Zheng
Reaction: ep → π+n
Polarization: beam (longitudinal), target (longitudinal)
Quantity: ALL
εL: 0.0378
Q2: 0.0245 GeV2
W: 1475.0 GeV
Ebeam: 1.3383 GeV
ε: 0.7648

Slice: cos(θπ+) =

Measurement data
cos(θπ+) φ(π+), [deg] ALL uncertainty syst. uncert.
0.35 42.0 -0.0025 0.855 0.03
0.45 18.0 -1.6321 0.691 0.1023
0.45 30.0 -0.3854 0.6988 0.0379
0.45 42.0 -0.7889 0.7718 0.056
0.45 138.0 0.4965 0.7816 0.0423
0.45 222.0 -0.239 0.8067 0.0332
0.45 234.0 -1.0975 0.7313 0.0723
0.45 246.0 -0.859 0.7317 0.0596
0.55 18.0 1.0979 0.8095 0.0723
0.55 30.0 0.4797 0.694 0.0416
0.55 42.0 -0.5337 0.7067 0.0439
0.55 126.0 0.1769 0.7379 0.0318
0.55 138.0 -0.5631 0.6679 0.0452
0.55 150.0 -0.2236 0.6574 0.0329
0.55 162.0 -0.9124 0.7468 0.0624
0.55 210.0 0.7857 0.8385 0.0558
0.55 222.0 -1.4244 0.5741 0.0905
0.55 234.0 -0.0193 0.6213 0.03
0.55 246.0 -0.5424 0.7014 0.0442
0.65 126.0 1.2524 0.6014 0.0808
0.65 138.0 0.7772 0.585 0.0554
0.65 150.0 -1.5881 0.7004 0.0998
0.65 162.0 -0.3747 0.7046 0.0375
0.65 198.0 1.1823 0.7946 0.077
0.65 210.0 -1.2 0.6134 0.0779
0.65 222.0 -0.6737 0.5688 0.0503
0.65 234.0 0.5322 0.4663 0.0438
0.65 246.0 0.2893 0.5943 0.0347
0.65 258.0 -1.1232 0.7575 0.0737
0.75 126.0 -0.4272 0.8214 0.0394
0.75 138.0 -0.3553 0.638 0.0368
0.75 150.0 -0.956 0.6796 0.0647
0.75 162.0 0.0453 0.6884 0.0301
0.75 222.0 -0.0939 0.5596 0.0305
0.75 234.0 -0.357 0.5178 0.0368
0.75 246.0 0.0037 0.5181 0.03
0.75 258.0 -0.7306 0.7737 0.0531
0.85 114.0 -0.5724 0.6617 0.0456
0.85 126.0 -2.5507 2.5507 0.1558
0.85 138.0 0.5378 0.8037 0.044
0.85 210.0 -1.1487 0.711 0.0751
0.85 222.0 0.3131 0.5977 0.0354
0.85 234.0 0.647 0.6016 0.049
0.85 246.0 0.6528 0.4932 0.0493
0.95 138.0 0.1069 0.6396 0.0307
0.95 222.0 0.3227 0.7442 0.0357
0.95 234.0 0.2608 0.7414 0.0338
0.25 30.0 0.4674 1.0764 0.0405
0.25 42.0 -1.2494 0.7594 0.0786
0.35 30.0 -0.3154 1.0932 0.0352
0.35 42.0 -1.2974 0.751 0.0812
0.35 54.0 2.3152 0.7329 0.1379
0.45 18.0 -2.1269 0.6404 0.1273
0.45 30.0 -0.7403 0.842 0.0525
0.45 42.0 -0.251 0.8496 0.0334
0.45 54.0 -1.3938 1.2937 0.0864
0.45 210.0 -0.9858 1.0314 0.0647
0.45 222.0 0.8591 0.9117 0.0583
0.45 234.0 -0.2316 1.0767 0.0329
0.45 246.0 -0.3325 1.1176 0.0357
0.55 30.0 -1.1873 0.98 0.0753
0.55 42.0 -0.3383 0.9857 0.0359
0.55 126.0 1.5291 1.119 0.0938
0.55 138.0 -0.9838 0.8429 0.0646
0.55 150.0 0.7358 0.9747 0.0523
0.55 162.0 1.7269 0.9615 0.1048
0.55 198.0 0.7822 1.0265 0.0545
0.55 210.0 -0.3433 1.0379 0.036
0.55 222.0 -1.7765 0.5728 0.1076
0.55 234.0 0.4797 0.7483 0.041
0.55 246.0 -1.1001 0.8823 0.0707
0.65 126.0 0.475 0.9537 0.0408
0.65 138.0 0.2255 0.8744 0.0327
0.65 150.0 0.6926 0.7279 0.0502
0.65 174.0 -0.2501 1.2191 0.0333
0.65 210.0 -1.0672 0.8252 0.0689
0.65 222.0 0.0055 0.6877 0.03
0.65 234.0 0.8571 0.5707 0.0582
0.65 246.0 0.9809 0.571 0.0644
0.75 126.0 -0.4123 1.1022 0.0384
0.75 138.0 0.4291 1.1853 0.039
0.75 150.0 1.2786 0.7844 0.0802
0.75 162.0 0.0435 1.1407 0.0301
0.75 210.0 1.2006 0.7304 0.076
0.75 222.0 -1.7029 0.5258 0.1035
0.75 234.0 -0.3565 0.6311 0.0365
0.75 246.0 0.6653 0.7663 0.049
0.75 258.0 -1.3225 1.0518 0.0825
0.85 126.0 -0.0007 0.8484 0.03
0.85 198.0 -0.4589 1.0402 0.0402
0.85 210.0 -1.287 0.7768 0.0806
0.85 222.0 -0.5435 0.6682 0.0436
0.85 234.0 0.5124 0.7034 0.0423
0.85 246.0 0.8598 0.5933 0.0583
0.85 258.0 -0.8598 0.7386 0.0583
0.95 234.0 -0.3595 0.7745 0.0366
