Measurement E151M2044

Experiment: EG4
Year: 2016

Experiment comment:

Final asymmetry results for the ep-> e pi+ (n) channel extracted from CLAS/EG4 data obtained using a longitudinally polarized beam and a longitudinally polarized NH3 target (CAA HS07-02).
Spokesperson: Xiaochao Zheng
Reaction: ep → π+n
Polarization: beam (longitudinal), target (longitudinal)
Quantity: ALL
εL: 0.2208
Q2: 0.1205 GeV2
W: 1445.0 GeV
Ebeam: 2.2596 GeV
ε: 0.918

Slice: cos(θπ+) =

Measurement data
cos(θπ+) φ(π+), [deg] ALL uncertainty syst. uncert.
0.25 66.0 1.2113 1.0523 0.1153
0.35 78.0 -1.2256 1.1999 0.1166
0.35 282.0 0.4464 0.8273 0.0508
0.35 294.0 0.2418 0.9864 0.0373
0.45 78.0 -2.9973 2.9973 0.2771
0.45 270.0 -1.8129 0.8432 0.1693
0.45 282.0 1.0754 0.9028 0.1033
0.45 294.0 1.0481 0.7889 0.1009
0.55 66.0 1.3491 1.1688 0.1276
0.55 78.0 1.8938 1.1189 0.1766
0.55 102.0 0.5646 1.1789 0.0599
0.55 114.0 2.3192 1.0749 0.2152
0.55 294.0 -1.7025 0.9466 0.1593
0.65 102.0 0.2104 0.9059 0.0357
0.65 114.0 0.3339 1.0132 0.0429
0.65 126.0 -2.1483 1.1722 0.1997
0.65 222.0 0.7003 1.0512 0.071
0.65 234.0 0.8124 1.0708 0.0805
0.65 246.0 0.205 0.9115 0.0354
0.65 258.0 -0.9518 1.0744 0.0925
0.75 102.0 -0.6543 0.9967 0.0672
0.75 114.0 -0.8376 0.9463 0.0826
0.75 126.0 1.0458 0.9481 0.1007
0.75 138.0 -1.3818 1.1981 0.1305
0.75 222.0 1.0377 1.0892 0.1
0.75 234.0 1.3073 0.7907 0.1238
0.75 246.0 -0.654 0.9278 0.0672
0.75 258.0 0.9496 0.9751 0.0923
0.85 78.0 -0.6178 1.4578 0.0642
0.85 90.0 0.2015 1.4049 0.0353
0.85 102.0 -0.5019 1.2882 0.055
0.85 114.0 -0.1844 1.2096 0.0345
0.85 126.0 0.0651 1.3666 0.0306
0.85 138.0 -0.0743 1.5576 0.0308
0.85 210.0 0.6372 1.3105 0.0658
0.85 222.0 1.6333 1.2121 0.1531
0.85 234.0 -0.005 0.963 0.03
0.85 246.0 -1.4961 1.0148 0.1407
0.85 258.0 -0.6554 0.9008 0.0673
0.85 270.0 0.2898 1.1329 0.0401
0.85 282.0 -0.4396 1.0783 0.0503
0.95 90.0 1.6099 3.4213 0.151
0.95 234.0 -1.6933 3.4365 0.1585
0.95 258.0 -2.1327 2.5521 0.1983
0.95 270.0 -2.0868 2.5645 0.1941
0.15 66.0 1.436 0.6734 0.0981
0.25 54.0 -0.6937 0.6992 0.0542
0.25 66.0 0.4036 0.6107 0.0399
0.25 78.0 0.7842 0.7445 0.0592
0.25 294.0 -0.4354 0.62 0.0413
0.35 66.0 -1.4592 0.6626 0.0996
0.35 78.0 -1.099 0.6254 0.0775
0.35 282.0 -0.2011 0.6329 0.0327
0.35 294.0 -0.4983 0.6742 0.0442
0.35 306.0 -0.5525 0.6568 0.0468
0.45 66.0 -0.1567 0.6007 0.0317
0.45 78.0 -0.5662 0.6429 0.0475
0.45 270.0 -0.0503 0.8021 0.0302
0.45 282.0 0.6217 0.5347 0.0504
0.45 294.0 -0.3137 0.6198 0.0363
0.55 90.0 -1.8347 0.6629 0.1231
0.55 102.0 1.5721 0.6082 0.1066
0.55 114.0 -0.2622 0.6837 0.0345
0.55 270.0 -0.3362 0.7109 0.0371
0.55 282.0 -0.4758 0.5924 0.0431
0.55 294.0 -0.269 0.6594 0.0347
0.65 102.0 -1.1809 0.677 0.0825
0.65 114.0 -0.1308 0.6792 0.0312
0.65 126.0 -0.1836 0.6265 0.0323
0.65 234.0 -1.3591 0.7621 0.0934
0.65 246.0 -0.8841 0.7714 0.0649
0.65 258.0 -0.1394 0.8273 0.0313
0.65 294.0 -0.6903 0.6477 0.054
0.75 102.0 0.119 0.6046 0.031
0.75 114.0 -1.2707 0.5907 0.0879
0.75 126.0 -0.3172 0.7314 0.0364
0.75 138.0 0.3532 0.717 0.0378
0.75 210.0 0.1532 0.8947 0.0316
0.75 222.0 -0.6347 0.8446 0.051
0.75 234.0 1.3275 0.7353 0.0914
0.75 246.0 -1.1096 0.6301 0.0782
0.75 258.0 -0.6324 0.6854 0.0509
0.85 78.0 1.5978 0.703 0.1082
0.85 102.0 -0.0778 0.7693 0.0304
0.85 114.0 -0.6117 0.8447 0.0498
0.85 126.0 -0.2707 0.6813 0.0348
0.85 210.0 0.1718 1.0536 0.032
0.85 222.0 0.2901 0.9551 0.0354
0.85 234.0 -1.6442 0.835 0.1111
0.85 246.0 -1.1345 0.6316 0.0797
0.85 258.0 -0.5207 0.6408 0.0452
0.85 270.0 -1.3007 0.8076 0.0898
0.95 90.0 3.2141 0.8661 0.2112
0.95 222.0 -0.4757 1.4026 0.0431
0.95 234.0 -1.5944 1.2291 0.108
0.95 246.0 0.48 1.3319 0.0433
0.95 258.0 0.3203 1.1597 0.0365
0.95 270.0 -0.829 1.0029 0.0617
0.95 282.0 2.0288 1.2741 0.1353
