Measurement E151M822

Experiment: EG4
Year: 2016

Experiment comment:

Final asymmetry results for the ep-> e pi+ (n) channel extracted from CLAS/EG4 data obtained using a longitudinally polarized beam and a longitudinally polarized NH3 target (CAA HS07-02).
Spokesperson: Xiaochao Zheng
Reaction: ep → π+n
Polarization: beam (longitudinal), target (longitudinal)
Quantity: AUL
εL: 0.2208
Q2: 0.1205 GeV2
W: 1445.0 GeV
Ebeam: 2.2596 GeV
ε: 0.918

Slice: cos(θπ+) =

Measurement data
cos(θπ+) φ(π+), [deg] AUL uncertainty syst. uncert.
0.25 66.0 -0.1029 0.9248 0.0315
0.35 78.0 0.2433 1.0653 0.0375
0.35 282.0 0.7205 0.74 0.073
0.35 294.0 -0.0672 0.8478 0.0306
0.45 78.0 -0.7292 0.9277 0.0737
0.45 270.0 -0.417 0.771 0.0488
0.45 282.0 1.7115 0.8071 0.1608
0.45 294.0 -0.2848 0.7106 0.0399
0.55 66.0 -0.2591 1.0192 0.0384
0.55 78.0 -0.4326 1.04 0.0499
0.55 102.0 -0.4286 0.9908 0.0496
0.55 114.0 -1.2559 0.8695 0.1197
0.55 294.0 0.0241 0.8756 0.0301
0.65 102.0 -0.2503 0.766 0.0379
0.65 114.0 0.8488 0.9008 0.0839
0.65 126.0 0.3861 1.1084 0.0466
0.65 222.0 -2.3066 0.6575 0.215
0.65 234.0 0.7889 0.9467 0.0787
0.65 246.0 -0.6259 0.7472 0.0651
0.65 258.0 2.077 0.9584 0.194
0.75 102.0 -0.794 0.8179 0.0792
0.75 114.0 0.7553 0.8439 0.0759
0.75 126.0 -0.7343 0.7882 0.0741
0.75 138.0 -0.8036 0.9887 0.08
0.75 222.0 3.0429 3.0429 0.2824
0.75 234.0 0.4653 0.711 0.0524
0.75 246.0 0.5752 0.8237 0.061
0.75 258.0 1.1719 0.8915 0.1122
0.85 78.0 0.5734 1.3083 0.0608
0.85 90.0 0.2746 1.2219 0.0393
0.85 102.0 0.3843 1.1269 0.0465
0.85 114.0 -1.1787 0.9582 0.1128
0.85 126.0 1.1872 1.2094 0.1136
0.85 138.0 1.8481 1.4219 0.1732
0.85 210.0 1.2902 1.1865 0.1228
0.85 222.0 0.1283 1.0661 0.0323
0.85 234.0 0.6193 0.8481 0.0645
0.85 246.0 0.8324 0.9291 0.0825
0.85 258.0 -1.0426 0.7228 0.1008
0.85 270.0 0.4569 0.9922 0.0518
0.85 282.0 -2.594 0.6117 0.2413
0.95 90.0 -3.8697 2.6757 0.3584
0.95 234.0 -7.7088 2.0656 0.7121
0.95 258.0 -0.3649 2.2211 0.0451
0.95 270.0 -2.7466 2.0416 0.2553
0.15 66.0 0.8239 0.65 0.0618
0.25 54.0 -0.2745 0.6075 0.035
0.25 66.0 -0.1653 0.5218 0.0319
0.25 78.0 -0.4253 0.6257 0.041
0.25 294.0 1.1834 0.54 0.0833
0.35 66.0 1.0519 0.6314 0.0753
0.35 78.0 -0.2714 0.5716 0.0349
0.35 282.0 -0.0272 0.5428 0.0301
0.35 294.0 -0.9699 0.5119 0.0704
0.35 306.0 -0.2688 0.5731 0.0348
0.45 66.0 -0.0939 0.5155 0.0306
0.45 78.0 0.4541 0.5773 0.0423
0.45 270.0 -0.253 0.6748 0.0343
0.45 282.0 -0.6638 0.4304 0.0529
0.45 294.0 -0.2794 0.5203 0.0352
0.55 90.0 1.0922 0.6514 0.0777
0.55 102.0 -0.5911 0.5459 0.049
0.55 114.0 -0.6239 0.553 0.0508
0.55 270.0 0.5495 0.6313 0.0469
0.55 282.0 -0.1755 0.51 0.0321
0.55 294.0 -0.6434 0.5293 0.0518
0.65 102.0 0.6245 0.625 0.0508
0.65 114.0 0.2846 0.594 0.0353
0.65 126.0 -0.2899 0.5262 0.0355
0.65 234.0 -0.1531 0.7193 0.0316
0.65 246.0 0.1453 0.7037 0.0315
0.65 258.0 0.3175 0.7247 0.0365
0.65 294.0 -1.252 0.4662 0.0875
0.75 102.0 -0.9895 0.4607 0.0715
0.75 114.0 -0.4497 0.5193 0.0421
0.75 126.0 0.2081 0.6336 0.033
0.75 138.0 -0.2914 0.6068 0.0356
0.75 210.0 0.8241 0.7904 0.0618
0.75 222.0 -1.2651 0.6176 0.0883
0.75 234.0 1.7025 0.6602 0.1157
0.75 246.0 -0.3198 0.5598 0.0366
0.75 258.0 0.9649 0.6119 0.0701
0.85 78.0 0.8801 0.6883 0.0651
0.85 102.0 -0.9445 0.6025 0.0689
0.85 114.0 -0.2268 0.7295 0.0335
0.85 126.0 -0.0531 0.5855 0.0302
0.85 210.0 1.0873 0.9269 0.0774
0.85 222.0 1.2495 0.864 0.0873
0.85 234.0 -0.5195 0.7573 0.0454
0.85 246.0 0.304 0.5665 0.036
0.85 258.0 0.2471 0.5656 0.0341
0.85 270.0 -0.2528 0.7278 0.0343
0.95 90.0 0.2625 0.8957 0.0346
0.95 222.0 1.4372 1.2446 0.099
0.95 234.0 -0.2611 1.0973 0.0345
0.95 246.0 -0.3881 1.133 0.0394
0.95 258.0 0.0718 1.0018 0.0304
0.95 270.0 -0.6781 0.843 0.0537
0.95 282.0 1.6416 1.2354 0.1118
