Measurement E161M2

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 0.455 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.61 6.6099 0.0765173736646 0.455619459119 0.494395995304
-0.59 6.7205 0.0676529160959 0.351753213125 0.399039652737
-0.57 6.5914 0.0604649219093 0.640853870409 0.667250855721
-0.55 6.4687 0.0558714908359 0.557708370487 0.587353286801
-0.53 6.4037 0.0547986317927 0.319941041371 0.368976578268
-0.51 6.7878 0.0559969523404 0.546538837896 0.579911282702
-0.49 6.5858 0.05328250446 0.432832744508 0.469978200559
-0.47 6.5763 0.0505766223392 0.339958372853 0.385738372815
-0.45 6.5611 0.0488005492091 0.422088280336 0.459535726474
-0.43 6.4336 0.0477515860194 0.298403461831 0.349189086812
-0.41 6.4088 0.0473201926164 0.28803890253 0.340276747805
-0.39 6.4274 0.0472028256 0.298187027309 0.348866003685
-0.37 6.4004 0.0469823923414 0.318655087532 0.366460227399
-0.35 6.7646 0.0489205347919 0.503629607227 0.53875656753
-0.33 6.5689 0.0474771096023 0.318581754129 0.366426340176
-0.31 6.6449 0.0470562690375 0.339050140163 0.384286945048
-0.29 6.7444 0.0464351683168 0.38007392063 0.425214507029
-0.27 6.8519 0.0470518501859 0.256825492103 0.319950921932
-0.25 6.8465 0.0468459876358 0.205426248183 0.280337821912
-0.23 6.8999 0.0463321853969 0.236300589496 0.303610338439
-0.21 7.0748 0.045823506005 0.534238379656 0.570629705431
-0.19 7.3465 0.0446979900973 0.523997041672 0.560969320256
-0.17 7.2607 0.0417222549325 0.534373702051 0.570455359279
-0.15 7.443 0.0400863104691 0.370035035791 0.420323584063
-0.13 7.7436 0.039580547516 0.400951107067 0.452333076321
-0.11 7.8179 0.0385604506175 0.287929403931 0.355927706153
-0.09 7.8077 0.0379513831441 0.308574954456 0.372787747873
-0.07 7.8408 0.0376541115033 0.349779084405 0.412843864443
-0.05 7.9924 0.0380776699029 0.360192908113 0.421776224639
-0.03 8.1765 0.0388097309479 0.411775138618 0.466689845429
-0.01 8.148 0.0385131374408 0.432488587415 0.485070927791
0.01 8.3194 0.0393532468176 0.329659402968 0.401983179145
0.03 8.3105 0.0394722211888 0.443145522097 0.499343607212
0.05 8.4726 0.0408248515526 0.494818735999 0.545850378707
0.07 8.4204 0.0415636323551 0.525960287917 0.574320965867
0.09 8.3619 0.0420963328562 0.701638303373 0.738642595419
0.11 8.6367 0.0442770079229 0.608892270085 0.655027274068
0.13 8.7657 0.0453277221542 0.764056645547 0.801395005418
0.15 9.0455 0.0473040226538 0.826246990579 0.863925297363
0.17 9.1716 0.0499068620934 0.90923135951 0.943763013987
0.19 9.2988 0.054366858591 0.744216826393 0.786351736223
0.21 9.397 0.0593405502932 0.909766777307 0.944858374213
0.23 9.5996 0.064115913302 0.920369441942 0.958138563935
0.25 9.7451 0.0678524411989 0.984664941096 1.0203110723
0.27 10.0142 0.0715913344422 0.931051620928 0.971769135784
0.29 10.2594 0.0772177287219 0.724597206985 0.780454741893
0.31 10.66 0.0827890746501 0.714922414755 0.775976975961
0.33 11.2059 0.0896638044082 0.944352880114 0.995196368193
0.35 11.0626 0.0929507932331 0.883725132627 0.938361979665
0.37 11.5434 0.0999378947368 0.781536196984 0.847658489107
0.39 11.7975 0.106071950571 0.606088138229 0.690568307976
