Measurement E161M60

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.035 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.984 0.0137387862797 0.0767805037204 0.0825555823403
-0.65 0.9644 0.0126681037386 0.0779776836516 0.0831640823848
-0.61 0.9284 0.0119095043732 0.0649165903725 0.0705414361406
-0.58 0.9107 0.0117949500951 0.0638191910968 0.0695085878786
-0.55 0.9211 0.0115637334272 0.0399604813438 0.048460413944
-0.53 0.9233 0.0113281724702 0.0604476840622 0.0663173368406
-0.49 0.9358 0.0111968706857 0.0527241888211 0.0597734090133
-0.46 0.9621 0.0106339064419 0.0536564072016 0.0604702857444
-0.43 0.9959 0.00964188898451 0.060030608666 0.0664377183974
-0.41 1.017 0.00897635809604 0.0800985954642 0.0852543766669
-0.38 0.9798 0.00831332535625 0.051128549965 0.0582512712654
-0.34 0.9636 0.00818411647915 0.0499337584952 0.0571526107364
-0.31 0.9476 0.0079514432759 0.051995524325 0.0584310586053
-0.28 0.9455 0.00803780760626 0.060266355862 0.0658856119463
-0.26 0.9291 0.00791307063366 0.0548319552191 0.0609126823689
-0.22 0.8846 0.00757957872189 0.0505347403911 0.0565460630396
-0.2 0.8589 0.00745864726027 0.0357297996223 0.0432016463923
-0.17 0.8395 0.0073392031972 0.0429778558845 0.0493254848498
-0.14 0.7946 0.00690683524299 0.0470962379275 0.0524282127866
-0.1 0.7713 0.00720841121495 0.0281930631141 0.0358241114429
-0.07 0.7161 0.00698786775415 0.0343973793224 0.0403075351042
-0.04 0.6948 0.00697820416729 0.034399341078 0.0397929081429
-0.02 0.6439 0.00644940226171 0.0280685804854 0.0337958336314
0.02 0.6305 0.00602553962762 0.0405548131816 0.0446420563667
0.04 0.6405 0.00581234807973 0.0414948985997 0.045463643725
0.07 0.6344 0.0054957829356 0.0290853291184 0.0344514990194
0.1 0.6323 0.00538833169453 0.03518985481 0.0397199304935
0.14 0.6889 0.00590308177992 0.038348319722 0.0430457718187
0.17 0.7166 0.00600358226203 0.0372189064861 0.0425214915905
0.2 0.7565 0.00610414387309 0.0361888025165 0.042131335219
0.23 0.8331 0.006204816286 0.0371858878455 0.0440329159232
0.26 0.9281 0.00661525782381 0.043398713851 0.0509407457141
0.28 1.043 0.00733561168895 0.0403384283426 0.0501786512597
0.31 1.1834 0.00836507548652 0.0392177958599 0.0513121558831
0.34 1.3145 0.00929194156456 0.0433145451547 0.057168627339
0.38 1.453 0.00980501491689 0.0783891681451 0.088199847394
0.41 1.6123 0.0095964096 0.057808900031 0.0735030673869
0.44 1.8214 0.00938919163881 0.0598682142741 0.0782631834498
0.46 2.0465 0.00918360812787 0.0629334675809 0.0845562773122
0.49 2.2927 0.0094944364422 0.0846693313818 0.105934058385
0.52 2.5212 0.00980690332883 0.0680974643221 0.0975559570471
0.55 2.7674 0.0104328841775 0.077500935012 0.108633806958
0.58 2.9565 0.0108539037097 0.085816331629 0.118250942819
0.61 3.2054 0.0114848095546 0.102458328844 0.135514718932
0.65 3.5143 0.0122240124985 0.113946186941 0.149716068475
0.68 3.6791 0.0124479657146 0.114123127146 0.152655287984
0.71 3.9194 0.0128804622071 0.155768365509 0.187668970016
0.73 4.2128 0.0137228142043 0.166334886209 0.202319263254
0.76 4.4933 0.015384453801 0.228683096405 0.260945227717
0.79 4.9364 0.0197143074485 0.281610788291 0.313178761302
0.82 5.1558 0.028079744477 0.211141014372 0.253380299626
