Measurement E161M77

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.205 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.3671 0.0100018263473 0.0340619064311 0.036852408408
-0.65 0.3138 0.00836506488951 0.0338826753577 0.0359936641948
-0.61 0.2988 0.00803699336772 0.0454955683293 0.0468383744049
-0.58 0.2924 0.00781347384268 0.0479677978076 0.0492067348584
-0.55 0.2866 0.0074726993865 0.0495395676594 0.0506871218386
-0.53 0.2699 0.00953748984565 0.0463284608793 0.0479184500714
-0.49 0.295 0.008306780289 0.0383097559537 0.0399396735489
-0.46 0.2954 0.00729517139698 0.0272400527586 0.0292118495351
-0.43 0.2814 0.00541987673344 0.0260419841063 0.0276610759924
-0.41 0.2834 0.00528811881188 0.0248434256783 0.0264996188101
-0.38 0.2826 0.00515575826682 0.0236444106861 0.0253411240094
-0.34 0.2885 0.00523962194218 0.0266905669086 0.0282111295919
-0.31 0.3043 0.00542822665268 0.0286910152383 0.0304161623437
-0.28 0.3272 0.00551162941367 0.0307093135906 0.0323317294754
-0.26 0.35 0.0059107358263 0.0327712252135 0.0346284354364
-0.22 0.344 0.00557383063283 0.0221081978478 0.0246865578441
-0.2 0.3661 0.00565971943888 0.0272177805097 0.0297101087654
-0.17 0.3695 0.00574893917963 0.0209246194304 0.0240862449475
-0.14 0.3797 0.00594585164835 0.0395556171507 0.041337784283
-0.1 0.3906 0.00603966942149 0.0260079294308 0.0286587720633
-0.07 0.4039 0.00592899819727 0.0536735221536 0.0551988920043
-0.04 0.4012 0.00551013215859 0.0280641843565 0.0308017031547
-0.02 0.4211 0.00540538138731 0.0332636716563 0.0355870326078
0.02 0.4384 0.00530196822386 0.0291212831612 0.0321215052237
0.04 0.4406 0.00520066100094 0.0270037613149 0.0301999999854
0.07 0.4861 0.00551558552772 0.0406273099809 0.043174393867
0.1 0.5068 0.00572714197658 0.032296127396 0.0354836180254
0.14 0.5378 0.00583545824453 0.0270783571709 0.0313068455896
0.17 0.58 0.00583857630775 0.0292224404645 0.0336544155687
0.2 0.6143 0.0060511888587 0.0303017014934 0.0351207071634
0.23 0.673 0.00657654723127 0.0386443919154 0.0434707852621
0.26 0.7233 0.00731028010396 0.0344325399121 0.0404073317419
0.28 0.8166 0.00856719549642 0.0396858055396 0.0461491085283
0.31 0.8851 0.00877888770811 0.0365607867887 0.0446268761091
0.34 0.987 0.00857351694915 0.0585758892986 0.065143129833
0.38 1.1048 0.00857650288744 0.0648352033869 0.0720913447739
0.41 1.2141 0.00847484488108 0.0523180370832 0.0626894613681
0.44 1.3237 0.00858118428334 0.0481411806699 0.0610962157169
0.46 1.456 0.00879315551082 0.0481029148406 0.063036052279
0.49 1.6171 0.00931955578579 0.0512596905956 0.0681809644022
0.52 1.7838 0.00984714587738 0.0628330623006 0.0804308215068
0.55 1.9275 0.0102704980426 0.0712637135572 0.0890494942324
0.58 2.062 0.0105904907196 0.0828256693684 0.100887804437
0.61 2.2647 0.0112264489229 0.0818335312973 0.103221716413
0.65 2.4334 0.0115511155224 0.104966336176 0.124611507464
0.68 2.5601 0.011666917108 0.126161694049 0.144955643284
0.71 2.8402 0.0123143746526 0.115746776097 0.140054118236
0.73 3.0726 0.0128595951973 0.0833133891482 0.11923603392
0.76 3.2318 0.0134077681955 0.100307884795 0.134557843424
0.79 3.4025 0.0150043476911 0.147941067829 0.175379139463
0.82 3.6097 0.0192754569727 0.19062795377 0.215434252173
0.85 3.8231 0.0297179374211 0.203845147589 0.230793891799
