Measurement E161M88

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.315 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.3206 0.0138637837838 0.0503252968118 0.0529142691826
-0.65 0.2722 0.0116037450199 0.0272307381742 0.030557926136
-0.61 0.1998 0.00911140065147 0.0225271475817 0.0248978681805
-0.58 0.193 0.00899943820225 0.026725458126 0.0287163893543
-0.53 0.1826 0.00822620035566 0.0343281171594 0.0357124552739
-0.49 0.1772 0.00561853658537 0.0217871991463 0.0229113348006
-0.46 0.1628 0.00463295830576 0.0193531831319 0.0203613300423
-0.43 0.1705 0.00461972274732 0.0260942170171 0.0268461876
-0.41 0.1909 0.00503496071829 0.0297773264509 0.0306713284835
-0.38 0.197 0.00512520325203 0.0236510526536 0.0247818943532
-0.34 0.2077 0.00510999487442 0.0191292433824 0.0205030091694
-0.31 0.2299 0.00541565819861 0.0222504077777 0.0237698182831
-0.28 0.2457 0.00550706896552 0.0282685725039 0.029492664511
-0.26 0.2682 0.00570638297872 0.0367597224323 0.0379283274378
-0.22 0.2835 0.00590844808336 0.021087916949 0.0231118259351
-0.2 0.3026 0.00611100278552 0.0294731342913 0.0312579193879
-0.17 0.3132 0.00642191596639 0.0328787012414 0.0345424839589
-0.14 0.3174 0.00610384615385 0.0339557515324 0.0355124092895
-0.1 0.3517 0.00652465589467 0.0252713051791 0.027765356907
-0.07 0.3763 0.00631552447552 0.0305541183901 0.032927709093
-0.04 0.389 0.00621304818625 0.030575121132 0.0329292169483
-0.02 0.4194 0.00611032403919 0.0390245299797 0.0411648440897
0.02 0.4274 0.00621864364982 0.0211028071866 0.0248681065437
0.04 0.4429 0.00622169047619 0.0358643355943 0.0382035924521
0.07 0.4581 0.00643428505641 0.0295066090192 0.0327453063747
0.1 0.4718 0.00622455277281 0.0316945569898 0.0346924821499
0.14 0.4926 0.00622475904905 0.0253468415149 0.0294843497806
0.17 0.546 0.00664567233385 0.0358899016331 0.0393744659862
0.2 0.5662 0.00706695230999 0.0390659466166 0.0427365296961
0.23 0.6012 0.00780368356429 0.0432008393764 0.0470308661364
0.26 0.6437 0.00864592956593 0.0422239020217 0.0466786597336
0.28 0.707 0.00906545400328 0.0611314775195 0.0646472002128
0.31 0.7586 0.00853543547715 0.0357964571042 0.0424075691254
0.34 0.843 0.00853217543421 0.0357972342837 0.0434886819947
0.38 0.8965 0.00842476212851 0.0400229107272 0.0475339468091
0.41 0.9822 0.00863333690642 0.0379298760064 0.0469682114861
0.44 1.0806 0.008947106955 0.0452234372548 0.0547161520058
0.46 1.2023 0.0094719012605 0.0558018197419 0.0653297725657
0.49 1.3103 0.00968098297462 0.04844211565 0.0609950225981
0.52 1.4519 0.010416559171 0.065274078278 0.0772517345265
0.55 1.5942 0.0109429608607 0.0988964185782 0.108449778056
0.58 1.6622 0.0110476642613 0.0946574831398 0.105494086842
0.61 1.8671 0.0118910161754 0.115791034775 0.126886846207
0.65 1.9918 0.0119987951807 0.080005243042 0.097674614322
0.68 2.1896 0.0124223664599 0.0768018542194 0.0982527435513
0.71 2.3701 0.0127447382455 0.062105810091 0.090264418957
0.73 2.6187 0.0134908476213 0.0843276765389 0.111488866018
0.76 2.725 0.0140311653117 0.0875831970186 0.116095569964
0.79 2.8934 0.0156297247974 0.105650138205 0.132964741038
0.82 2.9946 0.0183912325286 0.169102846121 0.18856768163
0.85 3.2984 0.0288489795918 0.169056163379 0.193598530032
