Measurement E187M78
| Experiment: | e1e | |
|---|---|---|
| Year: | 2022 | |
| Spokespersons: | Y. Tian, R. W. Gothe V.I. Mokeev, and G. Hollis | |
| Reaction: | ed → π− p | |
| Polarization: | none | |
| Quantity: | dσ/dΩ (quasi-free) | |
| Q2: | 0.7 GeV2 | |
| W: | 1.1375 GeV | |
| Publication: |
Y. Tian, R.W. Gothe, V.I. Mokeev and G. Hollis (For CLAS Collaboration) Exclusive π− Electroproduction off the Neutron in Deuterium in the Resonance Region //
CLAS-Notes 2021-101
|
|
| cos(θ) | φ, [degree] | dσ/dΩ (quasi-free), [μb/sr] | uncertainty | syst. uncert. |
|---|---|---|---|---|
| -0.7 | 150.0 | 2.61102 | 0.212709 | 0.346373 |
| -0.7 | 180.0 | 2.24157 | 0.181205 | 0.271445 |
| -0.5 | 90.0 | 2.71511 | 0.172496 | 0.275482 |
| -0.5 | 100.0 | 2.86723 | 0.189484 | 0.287939 |
| -0.5 | 112.5 | 2.74733 | 0.162143 | 0.274173 |
| -0.5 | 150.0 | 2.26075 | 0.152684 | 0.182084 |
| -0.5 | 157.5 | 2.26694 | 0.179765 | 0.180208 |
| -0.5 | 180.0 | 2.07395 | 0.137581 | 0.177388 |
| -0.5 | 202.5 | 2.2889 | 0.157537 | 0.211105 |
| -0.5 | 210.0 | 2.42094 | 0.141403 | 0.209638 |
| -0.5 | 220.0 | 2.90064 | 0.209969 | 0.238844 |
| -0.5 | 247.5 | 2.63857 | 0.155843 | 0.246571 |
| -0.5 | 260.0 | 2.60839 | 0.174953 | 0.264582 |
| -0.5 | 270.0 | 2.47101 | 0.160137 | 0.250842 |
| -0.3 | 90.0 | 2.80569 | 0.158314 | 0.249751 |
| -0.3 | 100.0 | 2.97614 | 0.174509 | 0.264283 |
| -0.3 | 112.5 | 2.81935 | 0.157032 | 0.249952 |
| -0.3 | 140.0 | 2.34429 | 0.159145 | 0.19941 |
| -0.3 | 150.0 | 2.27544 | 0.118033 | 0.183637 |
| -0.3 | 157.5 | 2.26694 | 0.131669 | 0.185876 |
| -0.3 | 180.0 | 2.21466 | 0.113471 | 0.189413 |
| -0.3 | 202.5 | 2.4766 | 0.124213 | 0.21785 |
| -0.3 | 210.0 | 2.51318 | 0.112962 | 0.204981 |
| -0.3 | 220.0 | 2.75194 | 0.17292 | 0.214807 |
| -0.3 | 247.5 | 2.81232 | 0.141572 | 0.202132 |
| -0.3 | 260.0 | 2.75338 | 0.147475 | 0.208966 |
| -0.3 | 270.0 | 2.63708 | 0.135405 | 0.199523 |
| -0.1 | 90.0 | 3.11508 | 0.153383 | 0.216882 |
| -0.1 | 100.0 | 3.2791 | 0.168929 | 0.22978 |
| -0.1 | 112.5 | 3.26033 | 0.167931 | 0.231457 |
| -0.1 | 140.0 | 2.67514 | 0.192836 | 0.211088 |
| -0.1 | 150.0 | 2.50506 | 0.118657 | 0.176419 |
| -0.1 | 157.5 | 2.36741 | 0.127018 | 0.164981 |
| -0.1 | 180.0 | 2.44619 | 0.113213 | 0.174053 |
| -0.1 | 202.5 | 2.67164 | 0.131787 | 0.206098 |
| -0.1 | 210.0 | 2.61922 | 0.118542 | 0.200329 |
| -0.1 | 220.0 | 2.62722 | 0.160799 | 0.226594 |
| -0.1 | 247.5 | 2.81455 | 0.156511 | 0.200974 |
| -0.1 | 260.0 | 2.94323 | 0.160375 | 0.210384 |
| -0.1 | 270.0 | 2.82347 | 0.146356 | 0.198366 |
| 0.1 | 90.0 | 2.94219 | 0.15391 | 0.233823 |
| 0.1 | 100.0 | 3.08516 | 0.170917 | 0.247355 |
| 0.1 | 112.5 | 3.12821 | 0.178452 | 0.249761 |
| 0.1 | 140.0 | 2.2919 | 0.152164 | 0.192852 |
| 0.1 | 150.0 | 2.19473 | 0.100603 | 0.154205 |
| 0.1 | 157.5 | 2.09974 | 0.10595 | 0.138236 |
| 0.1 | 180.0 | 2.24166 | 0.107562 | 0.158498 |
| 0.1 | 202.5 | 2.51131 | 0.128631 | 0.196598 |
| 0.1 | 210.0 | 2.51462 | 0.117383 | 0.190546 |
| 0.1 | 220.0 | 2.58467 | 0.16179 | 0.20596 |
| 0.1 | 247.5 | 2.90493 | 0.150604 | 0.218311 |
| 0.1 | 260.0 | 3.10999 | 0.156213 | 0.23239 |
| 0.1 | 270.0 | 2.92203 | 0.140086 | 0.211421 |
| 0.3 | 90.0 | 2.86538 | 0.154576 | 0.200661 |
| 0.3 | 100.0 | 3.05751 | 0.173741 | 0.21363 |
| 0.3 | 112.5 | 2.98015 | 0.170031 | 0.231198 |
| 0.3 | 140.0 | 2.37691 | 0.159254 | 0.183917 |
| 0.3 | 150.0 | 2.23859 | 0.105968 | 0.160157 |
| 0.3 | 157.5 | 2.17424 | 0.114872 | 0.158023 |
| 0.3 | 180.0 | 2.16558 | 0.104104 | 0.164274 |
| 0.3 | 202.5 | 2.12413 | 0.127284 | 0.164376 |
| 0.3 | 210.0 | 2.23073 | 0.115714 | 0.174033 |
| 0.3 | 220.0 | 2.25641 | 0.181993 | 0.184318 |
| 0.3 | 247.5 | 3.05259 | 0.190694 | 0.253606 |
| 0.3 | 260.0 | 2.88137 | 0.190714 | 0.234283 |
| 0.3 | 270.0 | 2.60373 | 0.18448 | 0.210824 |
| 0.5 | 90.0 | 2.3757 | 0.148275 | 0.230119 |
| 0.5 | 100.0 | 2.54589 | 0.166252 | 0.249859 |
| 0.5 | 112.5 | 2.28962 | 0.145036 | 0.253991 |
| 0.5 | 140.0 | 1.89467 | 0.144911 | 0.177504 |
| 0.5 | 150.0 | 1.94314 | 0.111296 | 0.168874 |
| 0.5 | 157.5 | 1.98392 | 0.128834 | 0.16115 |
| 0.5 | 180.0 | 1.92006 | 0.141833 | 0.178792 |
| 0.5 | 202.5 | 1.9256 | 0.129357 | 0.160765 |
| 0.5 | 210.0 | 1.90684 | 0.112705 | 0.167411 |
| 0.5 | 220.0 | 2.01866 | 0.13036 | 0.173789 |
| 0.5 | 247.5 | 2.34211 | 0.147116 | 0.205563 |
| 0.5 | 260.0 | 2.41413 | 0.162432 | 0.199459 |
| 0.5 | 270.0 | 2.32795 | 0.147828 | 0.189124 |
| 0.7 | 90.0 | 2.08372 | 0.146551 | 0.148742 |
| 0.7 | 100.0 | 2.30808 | 0.167589 | 0.165135 |
| 0.7 | 112.5 | 1.85217 | 0.117986 | 0.133533 |
| 0.7 | 140.0 | 1.75418 | 0.100873 | 0.142284 |
| 0.7 | 150.0 | 1.79519 | 0.0807935 | 0.146407 |
| 0.7 | 157.5 | 1.90268 | 0.0960131 | 0.157254 |
| 0.7 | 180.0 | 1.88298 | 0.109414 | 0.148118 |
| 0.7 | 202.5 | 1.99009 | 0.117006 | 0.166724 |
| 0.7 | 210.0 | 1.91368 | 0.0970557 | 0.152802 |
| 0.7 | 220.0 | 1.94205 | 0.121455 | 0.165604 |
| 0.7 | 247.5 | 1.78192 | 0.11177 | 0.140803 |
| 0.7 | 260.0 | 1.91179 | 0.14078 | 0.149773 |
| 0.7 | 270.0 | 1.78455 | 0.126082 | 0.139162 |
| 0.9 | 90.0 | 1.5967 | 0.0905223 | 0.125674 |
| 0.9 | 100.0 | 1.71908 | 0.108319 | 0.136642 |
| 0.9 | 112.5 | 1.73303 | 0.0958869 | 0.134476 |
| 0.9 | 140.0 | 1.54488 | 0.0812636 | 0.117575 |
| 0.9 | 150.0 | 1.57928 | 0.0665419 | 0.116842 |
| 0.9 | 157.5 | 1.5808 | 0.0766755 | 0.118142 |
| 0.9 | 180.0 | 1.59604 | 0.0913326 | 0.118713 |
| 0.9 | 202.5 | 1.49092 | 0.0804107 | 0.116335 |
| 0.9 | 210.0 | 1.49502 | 0.0678939 | 0.118676 |
| 0.9 | 220.0 | 1.4552 | 0.0767007 | 0.117334 |
| 0.9 | 247.5 | 1.62049 | 0.0912731 | 0.143624 |
| 0.9 | 260.0 | 1.81821 | 0.118007 | 0.147321 |
| 0.9 | 270.0 | 1.72159 | 0.101145 | 0.140542 |
Experiment comment:
