Measurement E8M71
| Experiment: | E89-038 CLAS experiment | |
|---|---|---|
| Year: | 1999 | |
| Spokespersons: | V. Burkert, R. Minehart | |
| Reaction: | ep → π+n | |
| Polarization: | none | |
| Quantity: | dσ/dΩ | |
| Q2: | 0.55 — 0.65 GeV2 | |
| W: | 1.14 — 1.16 GeV | |
| Ebeam: | 1.515 GeV | |
| Publication: |
under preparation //
|
|
| θπ, [deg] | φπ, [deg] | dσ/dΩ, [μb/sr] | uncertainty |
|---|---|---|---|
| 7.5 | 135.0 | 3.221 | 1.37 |
| 22.5 | 15.0 | 1.575 | 0.5635 |
| 22.5 | 45.0 | 3.175 | 0.9893 |
| 22.5 | 75.0 | 4.447 | 1.485 |
| 22.5 | 105.0 | 5.115 | 1.08 |
| 22.5 | 135.0 | 3.889 | 0.6696 |
| 22.5 | 165.0 | 4.135 | 0.6083 |
| 22.5 | 195.0 | 3.848 | 0.5461 |
| 22.5 | 225.0 | 3.792 | 0.6724 |
| 22.5 | 255.0 | 6.203 | 2.292 |
| 22.5 | 285.0 | 4.493 | 0.9927 |
| 22.5 | 315.0 | 3.482 | 1.45 |
| 22.5 | 345.0 | 1.671 | 0.8627 |
| 37.5 | 75.0 | 3.865 | 0.7563 |
| 37.5 | 105.0 | 5.518 | 0.9719 |
| 37.5 | 135.0 | 3.826 | 0.4552 |
| 37.5 | 165.0 | 3.313 | 0.4035 |
| 37.5 | 195.0 | 3.613 | 0.4381 |
| 37.5 | 225.0 | 4.585 | 0.5775 |
| 37.5 | 255.0 | 4.394 | 0.6518 |
| 37.5 | 285.0 | 4.641 | 1.169 |
| 37.5 | 315.0 | 2.042 | 0.6999 |
| 52.5 | 75.0 | 4.099 | 0.6845 |
| 52.5 | 105.0 | 5.136 | 0.7976 |
| 52.5 | 135.0 | 4.711 | 0.5917 |
| 52.5 | 165.0 | 3.855 | 0.3736 |
| 52.5 | 195.0 | 3.464 | 0.3656 |
| 52.5 | 225.0 | 4.729 | 0.6216 |
| 52.5 | 255.0 | 5.166 | 0.7248 |
| 52.5 | 285.0 | 4.403 | 0.6536 |
| 67.5 | 45.0 | 3.013 | 0.4182 |
| 67.5 | 75.0 | 4.659 | 0.4668 |
| 67.5 | 105.0 | 6.505 | 0.6811 |
| 67.5 | 135.0 | 5.285 | 0.6373 |
| 67.5 | 165.0 | 3.933 | 0.4122 |
| 67.5 | 195.0 | 4.875 | 0.4726 |
| 67.5 | 225.0 | 6.226 | 0.7334 |
| 67.5 | 255.0 | 5.109 | 0.572 |
| 67.5 | 285.0 | 4.797 | 0.4872 |
| 67.5 | 315.0 | 2.723 | 0.3749 |
| 82.5 | 45.0 | 3.764 | 0.4431 |
| 82.5 | 75.0 | 4.981 | 0.4001 |
| 82.5 | 105.0 | 6.47 | 0.6526 |
| 82.5 | 135.0 | 3.967 | 0.5378 |
| 82.5 | 165.0 | 3.451 | 0.3777 |
| 82.5 | 195.0 | 4.526 | 0.4945 |
| 82.5 | 225.0 | 5.551 | 0.832 |
| 82.5 | 255.0 | 5.512 | 0.5386 |
| 82.5 | 285.0 | 5.101 | 0.3956 |
| 82.5 | 315.0 | 4.192 | 0.4843 |
| 97.5 | 45.0 | 3.934 | 0.6626 |
| 97.5 | 75.0 | 5.24 | 0.4476 |
| 97.5 | 105.0 | 6.738 | 0.5933 |
| 97.5 | 135.0 | 4.698 | 0.5274 |
| 97.5 | 165.0 | 3.213 | 0.3609 |
| 97.5 | 195.0 | 3.468 | 0.3561 |
| 97.5 | 225.0 | 5.299 | 0.7408 |
| 97.5 | 255.0 | 7.122 | 0.627 |
| 97.5 | 285.0 | 6.211 | 0.5126 |
| 97.5 | 315.0 | 5.142 | 0.7859 |
| 112.5 | 15.0 | 1.256 | 0.4549 |
| 112.5 | 45.0 | 3.745 | 0.5528 |
| 112.5 | 75.0 | 4.54 | 0.6005 |
| 112.5 | 105.0 | 5.586 | 0.5048 |
| 112.5 | 135.0 | 5.379 | 0.8065 |
| 112.5 | 165.0 | 3.28 | 0.4553 |
| 112.5 | 195.0 | 2.869 | 0.4168 |
| 112.5 | 225.0 | 4.612 | 0.5828 |
| 112.5 | 255.0 | 5.989 | 0.5018 |
| 112.5 | 285.0 | 5.5 | 0.6809 |
| 112.5 | 315.0 | 3.325 | 0.5599 |
| 127.5 | 15.0 | 1.778 | 1.194 |
| 127.5 | 45.0 | 2.743 | 0.4708 |
| 127.5 | 75.0 | 5.514 | 1.343 |
| 127.5 | 105.0 | 4.616 | 0.5064 |
| 127.5 | 135.0 | 4.821 | 1.026 |
| 127.5 | 165.0 | 3.839 | 0.9656 |
| 127.5 | 195.0 | 3.038 | 0.602 |
| 127.5 | 225.0 | 4.072 | 0.7307 |
| 127.5 | 255.0 | 5.41 | 0.6712 |
| 127.5 | 285.0 | 5.594 | 0.8833 |
| 127.5 | 315.0 | 4.935 | 0.8169 |
| 142.5 | 15.0 | 2.527 | 1.367 |
| 142.5 | 45.0 | 3.56 | 0.9914 |
| 142.5 | 75.0 | 7.34 | 2.062 |
| 142.5 | 105.0 | 7.383 | 2.551 |
| 142.5 | 255.0 | 6.895 | 1.677 |
| 142.5 | 285.0 | 2.988 | 1.28 |
| 142.5 | 315.0 | 7.04 | 2.098 |
Measurement comment:
Experiment comment:
