Measurement E142M268
| Experiment: | E00-112 CLAS experiment | |
|---|---|---|
| Year: | 0 | |
| Spokesperson: | Daniel S. Carman | |
| Reaction: | ep → K+ Σ0 | |
| Polarization: | none | |
| Quantity: | dσ/dΩ | |
| Q2: | 2.6 GeV2 | |
| W: | 1.975 GeV | |
| Publication: |
D. S. Carman et al. (CLAS Collaboration) //
Phys. Rev. C 87, 025204 (2013)
|
|
| cos(θ) | φ, [degree] | dσ/dΩ, [nb/sr] | uncertainty |
|---|---|---|---|
| -0.775 | -157.5 | 5.126 | 1.966 |
| -0.775 | -112.5 | 6.238 | 2.431 |
| -0.775 | -67.5 | 6.488 | 2.894 |
| -0.775 | -22.5 | 3.472 | 2.166 |
| -0.775 | 22.5 | 6.871 | 3.058 |
| -0.775 | 67.5 | 7.407 | 3.095 |
| -0.775 | 112.5 | 5.89 | 2.362 |
| -0.775 | 157.5 | 6.707 | 2.253 |
| -0.525 | -157.5 | 3.35 | 1.367 |
| -0.525 | -112.5 | 10.229 | 2.461 |
| -0.525 | -67.5 | 6.541 | 2.12 |
| -0.525 | -22.5 | 7.013 | 2.383 |
| -0.525 | 22.5 | 5.71 | 2.147 |
| -0.525 | 67.5 | 7.625 | 2.291 |
| -0.525 | 112.5 | 8.901 | 2.292 |
| -0.525 | 157.5 | 2.794 | 1.247 |
| -0.3 | -157.5 | 7.253 | 2.04 |
| -0.3 | -112.5 | 10.308 | 2.586 |
| -0.3 | -67.5 | 10.66 | 2.757 |
| -0.3 | -22.5 | 11.531 | 3.442 |
| -0.3 | 22.5 | 7.936 | 2.846 |
| -0.3 | 67.5 | 12.995 | 3.049 |
| -0.3 | 112.5 | 10.449 | 2.604 |
| -0.3 | 157.5 | 10.445 | 2.455 |
| -0.1 | -157.5 | 13.283 | 2.669 |
| -0.1 | -112.5 | 14.548 | 2.858 |
| -0.1 | -67.5 | 18.517 | 3.321 |
| -0.1 | -22.5 | 13.24 | 4.834 |
| -0.1 | 22.5 | 16.342 | 5.381 |
| -0.1 | 67.5 | 15.27 | 3.01 |
| -0.1 | 112.5 | 16.114 | 3.011 |
| -0.1 | 157.5 | 16.75 | 3.005 |
| 0.1 | -157.5 | 18.518 | 2.976 |
| 0.1 | -112.5 | 14.486 | 3.145 |
| 0.1 | -67.5 | 17.172 | 3.007 |
| 0.1 | -22.5 | 20.299 | 8.577 |
| 0.1 | 22.5 | 13.957 | 7.093 |
| 0.1 | 67.5 | 17.284 | 3.017 |
| 0.1 | 112.5 | 16.45 | 3.354 |
| 0.1 | 157.5 | 19.875 | 3.085 |
| 0.3 | -157.5 | 26.462 | 3.507 |
| 0.3 | -112.5 | 15.54 | 3.418 |
| 0.3 | -67.5 | 17.743 | 2.965 |
| 0.3 | -22.5 | 23.743 | 6.26 |
| 0.3 | 22.5 | 17.885 | 5.422 |
| 0.3 | 67.5 | 17.889 | 2.978 |
| 0.3 | 112.5 | 19.825 | 3.865 |
| 0.3 | 157.5 | 20.66 | 3.092 |
| 0.5 | -157.5 | 23.101 | 3.384 |
| 0.5 | -112.5 | 18.444 | 3.838 |
| 0.5 | -67.5 | 20.474 | 3.655 |
| 0.5 | -22.5 | 23.934 | 6.343 |
| 0.5 | 22.5 | 17.554 | 5.422 |
| 0.5 | 67.5 | 24.407 | 3.996 |
| 0.5 | 112.5 | 21.432 | 4.14 |
| 0.5 | 157.5 | 21.799 | 3.287 |
| 0.675 | -157.5 | 27.024 | 4.267 |
| 0.675 | -112.5 | 27.715 | 5.595 |
| 0.675 | -67.5 | 21.155 | 6.203 |
| 0.675 | -22.5 | 35.297 | 10.89 |
| 0.675 | 22.5 | 19.157 | 7.993 |
| 0.675 | 67.5 | 21.113 | 6.197 |
| 0.675 | 112.5 | 24.921 | 5.304 |
| 0.675 | 157.5 | 32.573 | 4.69 |
| 0.825 | -157.5 | 32.132 | 4.743 |
| 0.825 | -112.5 | 28.495 | 5.668 |
| 0.825 | -67.5 | 24.3 | 6.986 |
| 0.825 | -22.5 | 21.076 | 5.257 |
| 0.825 | 22.5 | 22.417 | 5.423 |
| 0.825 | 67.5 | 24.668 | 7.039 |
| 0.825 | 112.5 | 25.352 | 5.344 |
| 0.825 | 157.5 | 26.257 | 4.284 |
| 0.95 | -157.5 | 48.243 | 7.662 |
| 0.95 | -112.5 | 36.669 | 7.609 |
| 0.95 | -67.5 | 29.787 | 6.646 |
| 0.95 | -22.5 | 30.855 | 5.84 |
| 0.95 | 22.5 | 36.68 | 6.373 |
| 0.95 | 67.5 | 29.636 | 6.629 |
| 0.95 | 112.5 | 36.346 | 7.575 |
| 0.95 | 157.5 | 35.992 | 6.609 |
Experiment comment:
