Measurement E142M272
| Experiment: | E00-112 CLAS experiment | |
|---|---|---|
| Year: | 0 | |
| Spokesperson: | Daniel S. Carman | |
| Reaction: | ep → K+ Σ0 | |
| Polarization: | none | |
| Quantity: | dσ/dΩ | |
| Q2: | 2.6 GeV2 | |
| W: | 2.175 GeV | |
| Publication: |
D. S. Carman et al. (CLAS Collaboration) //
Phys. Rev. C 87, 025204 (2013)
|
|
| cos(θ) | φ, [degree] | dσ/dΩ, [nb/sr] | uncertainty |
|---|---|---|---|
| -0.775 | -157.5 | 3.096 | 1.335 |
| -0.775 | -112.5 | 1.498 | 0.954 |
| -0.775 | -67.5 | 1.896 | 1.282 |
| -0.775 | -22.5 | 3.49 | 1.912 |
| -0.775 | 22.5 | 2.72 | 1.686 |
| -0.775 | 67.5 | 2.582 | 1.498 |
| -0.775 | 112.5 | 3.162 | 1.391 |
| -0.775 | 157.5 | 1.562 | 0.944 |
| -0.525 | -157.5 | 1.635 | 0.956 |
| -0.525 | -112.5 | 2.383 | 1.126 |
| -0.525 | -67.5 | 4.384 | 1.696 |
| -0.525 | -22.5 | 1.826 | 1.211 |
| -0.525 | 22.5 | 2.856 | 1.517 |
| -0.525 | 67.5 | 3.326 | 1.475 |
| -0.525 | 112.5 | 1.864 | 0.995 |
| -0.525 | 157.5 | 1.46 | 0.903 |
| -0.3 | -157.5 | 3.29 | 1.528 |
| -0.3 | -112.5 | 3.138 | 1.581 |
| -0.3 | -67.5 | 2.517 | 1.669 |
| -0.3 | -22.5 | 1.777 | 1.393 |
| -0.3 | 22.5 | 2.459 | 1.64 |
| -0.3 | 67.5 | 1.409 | 1.248 |
| -0.3 | 112.5 | 2.488 | 1.408 |
| -0.3 | 157.5 | 2.278 | 1.27 |
| -0.1 | -157.5 | 3.535 | 1.617 |
| -0.1 | -112.5 | 3.092 | 1.523 |
| -0.1 | -67.5 | 2.563 | 1.576 |
| -0.1 | -22.5 | 3.355 | 2.085 |
| -0.1 | 22.5 | 3.465 | 2.119 |
| -0.1 | 67.5 | 3.595 | 1.868 |
| -0.1 | 112.5 | 2.962 | 1.491 |
| -0.1 | 157.5 | 2.908 | 1.466 |
| 0.1 | -157.5 | 6.444 | 1.893 |
| 0.1 | -112.5 | 3.88 | 1.572 |
| 0.1 | -67.5 | 5.084 | 2.015 |
| 0.1 | -22.5 | 7.741 | 3.001 |
| 0.1 | 22.5 | 3.941 | 2.138 |
| 0.1 | 67.5 | 6.945 | 2.357 |
| 0.1 | 112.5 | 3.972 | 1.591 |
| 0.1 | 157.5 | 6.286 | 1.87 |
| 0.3 | -157.5 | 5.253 | 1.912 |
| 0.3 | -112.5 | 6.678 | 2.274 |
| 0.3 | -67.5 | 6.832 | 2.233 |
| 0.3 | -22.5 | 7.397 | 5.33 |
| 0.3 | 22.5 | 6.716 | 5.078 |
| 0.3 | 67.5 | 6.02 | 2.095 |
| 0.3 | 112.5 | 5.216 | 2.009 |
| 0.3 | 157.5 | 6.581 | 2.141 |
| 0.5 | -157.5 | 11.384 | 2.834 |
| 0.5 | -112.5 | 9.274 | 2.932 |
| 0.5 | -67.5 | 8.717 | 2.487 |
| 0.5 | -22.5 | 3.064 | 3.945 |
| 0.5 | 22.5 | 8.891 | 6.729 |
| 0.5 | 67.5 | 9.543 | 2.603 |
| 0.5 | 112.5 | 9.974 | 3.041 |
| 0.5 | 157.5 | 11.95 | 2.904 |
| 0.675 | -157.5 | 11.557 | 3.422 |
| 0.675 | -112.5 | 6.956 | 3.747 |
| 0.675 | -67.5 | 11.81 | 4.17 |
| 0.675 | -22.5 | 7.339 | 6.511 |
| 0.675 | 22.5 | 5.174 | 5.464 |
| 0.675 | 67.5 | 9.721 | 3.782 |
| 0.675 | 112.5 | 7.513 | 3.894 |
| 0.675 | 157.5 | 10.79 | 3.306 |
| 0.825 | -157.5 | 17.815 | 4.309 |
| 0.825 | -112.5 | 17.764 | 6.249 |
| 0.825 | -67.5 | 13.996 | 7.002 |
| 0.825 | -22.5 | 0.0 | 0.0 |
| 0.825 | 22.5 | 12.742 | 8.911 |
| 0.825 | 67.5 | 15.722 | 7.423 |
| 0.825 | 112.5 | 17.842 | 6.263 |
| 0.825 | 157.5 | 17.481 | 4.268 |
| 0.95 | -157.5 | 24.34 | 6.411 |
| 0.95 | -112.5 | 18.593 | 6.184 |
| 0.95 | -67.5 | 24.086 | 8.184 |
| 0.95 | -22.5 | 22.6 | 7.857 |
| 0.95 | 22.5 | 27.415 | 8.658 |
| 0.95 | 67.5 | 21.213 | 7.679 |
| 0.95 | 112.5 | 22.126 | 6.748 |
| 0.95 | 157.5 | 23.834 | 6.344 |
Experiment comment:
