Measurement E161M66

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.095 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.703 0.0142130637636 0.0864392782157 0.0897833375911
-0.65 0.65 0.0125884136073 0.0492155650466 0.053734450917
-0.61 0.6069 0.0116037878788 0.0481207035159 0.0521524815084
-0.58 0.6086 0.0114850826743 0.0547074298059 0.0582581171367
-0.55 0.5956 0.0111408765817 0.0469975623729 0.0510030756546
-0.53 0.6336 0.0112228374893 0.0740544253822 0.0769021333025
-0.49 0.6802 0.0111917891374 0.0870837749291 0.089722073844
-0.46 0.7265 0.0108303518187 0.0864240329971 0.08925497592
-0.43 0.7261 0.00949714625446 0.0864800798625 0.0891424070622
-0.41 0.6892 0.0086015600624 0.072994953007 0.0760053179373
-0.38 0.6746 0.00824772943792 0.0428127896676 0.0472497366697
-0.34 0.6743 0.00821536392405 0.0437350865507 0.0480544522992
-0.31 0.6877 0.00818563920235 0.0372102850143 0.0426352928144
-0.28 0.6777 0.00804894514768 0.0296260777358 0.0355899131291
-0.26 0.6874 0.00823233532934 0.0612492339138 0.0646540987721
-0.22 0.6881 0.00830937022317 0.0452432797937 0.0497438310775
-0.2 0.6686 0.00786341539909 0.0619025580914 0.0648956528868
-0.17 0.6364 0.00763094612352 0.0292200044706 0.0350405144424
-0.14 0.6471 0.00792324794587 0.0302805571611 0.0359693851061
-0.1 0.5834 0.00748882153682 0.0322417051657 0.0365926687032
-0.07 0.5897 0.00757622316086 0.0415143450221 0.0453495313557
-0.04 0.5825 0.00756358946994 0.0351964787206 0.0392115036764
-0.02 0.5494 0.00693347146355 0.03000944807 0.0344904933521
0.02 0.5534 0.00651423766816 0.0402766024834 0.0436486297846
0.04 0.5657 0.00630507948109 0.0341223676309 0.0380062248378
0.07 0.5757 0.00620143626571 0.0258670096502 0.030788330963
0.1 0.5994 0.00641069518717 0.0341026829915 0.0384419690738
0.14 0.6411 0.00682681510165 0.0361612305594 0.0407853505343
0.17 0.6637 0.00682946679139 0.0434667503196 0.0477799237715
0.2 0.7443 0.00714378912227 0.0351820448095 0.041443633271
0.23 0.8126 0.00735337751721 0.0372817359989 0.0437839873848
0.26 0.8743 0.00777017419125 0.038320156485 0.045788743611
0.28 0.9987 0.00901596970011 0.0414303305607 0.0502369791818
0.31 1.1043 0.0101578186597 0.0466058871826 0.0563810653642
0.34 1.2393 0.0109892755563 0.0528699898123 0.0639253768118
0.38 1.3604 0.0109901989178 0.0622370912539 0.0733989839443
0.41 1.5294 0.0106813262815 0.0518104166058 0.0672240530091
0.44 1.7316 0.0105787733589 0.0549917225973 0.0735667841801
0.46 1.916 0.0105821962313 0.0570264598491 0.0778129882283
0.49 2.0876 0.0107918480962 0.0705797139033 0.0914068072534
0.52 2.3512 0.0116267561482 0.0519139532445 0.0835030451385
0.55 2.5298 0.0121520137948 0.0789704917088 0.105955476868
0.58 2.7658 0.0127844193912 0.093530308568 0.121113075474
0.61 3.0099 0.0135234326398 0.104024645011 0.133258034399
0.65 3.1797 0.013955645082 0.135382605863 0.161230811031
0.68 3.3706 0.0141814626903 0.166798219763 0.190900757173
0.71 3.669 0.0149345876861 0.188007760719 0.213593215024
0.73 3.9108 0.015584210104 0.14647328219 0.18065652332
0.76 4.1741 0.0169632039736 0.188438026181 0.22150302601
0.79 4.4834 0.0202285440434 0.262020316017 0.291346478871
0.82 4.8457 0.0284506133229 0.169225064933 0.219888765929
