Measurement E161M67

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.105 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.6638 0.0123737050478 0.0635057589781 0.0673247332692
-0.65 0.6251 0.0109628200631 0.0775287467735 0.0802406353712
-0.61 0.5491 0.00942943290735 0.0416458376677 0.0453753221067
-0.58 0.5943 0.0102994469027 0.0713605731024 0.0739495008695
-0.55 0.5846 0.00973604041916 0.0437292752851 0.0477105559378
-0.53 0.5815 0.00949521396396 0.0425535064569 0.0465722187396
-0.49 0.6136 0.00946846399432 0.0669336103134 0.0695432498387
-0.46 0.6562 0.00900241322314 0.0607364516263 0.0641088514544
-0.43 0.6486 0.00778060646451 0.0583838347751 0.061385358851
-0.41 0.655 0.00753492193919 0.0420299292335 0.0464558599045
-0.38 0.6451 0.00718326408509 0.0429028054687 0.0467601528452
-0.34 0.6426 0.00726101694915 0.0362805406915 0.0407540002672
-0.31 0.6264 0.00691390728477 0.0372640293857 0.0415457724818
-0.28 0.6325 0.00699246231156 0.0413124130356 0.0451991235353
-0.26 0.6387 0.00696648487853 0.0348097412866 0.0397773337712
-0.22 0.6265 0.00683722296844 0.0410342830092 0.0448755149136
-0.2 0.6255 0.0068137254902 0.0346361537262 0.0390819431646
-0.17 0.635 0.00689763001975 0.0313501626808 0.0366887296719
-0.14 0.6161 0.00687797699594 0.0312520948489 0.0360834920038
-0.1 0.577 0.00665249504594 0.0301753924525 0.034610890883
-0.07 0.5666 0.00663903332113 0.0269956151358 0.0318584508869
-0.04 0.5437 0.00631727619048 0.0279961072568 0.032154336179
-0.02 0.5518 0.00620697412823 0.0309844069198 0.0352044144807
0.02 0.5488 0.00578881145225 0.0258600011982 0.0307030638016
0.04 0.5544 0.00547785234899 0.0300040519537 0.0342140912214
0.07 0.5696 0.00547791689349 0.0330490911601 0.0369135436152
0.1 0.5976 0.00558408029071 0.0361715087784 0.0401660431834
0.14 0.6393 0.00600087392782 0.0247838558764 0.0309776495905
0.17 0.6596 0.00600389202762 0.0300052208877 0.0352992356622
0.2 0.7159 0.00611083622685 0.0362890848687 0.0417313027457
0.23 0.815 0.0066310704297 0.0445087508807 0.0499841901065
0.26 0.8932 0.00704857839155 0.0373405616275 0.0454189588339
0.28 0.9858 0.00788142225963 0.0435932699297 0.0518602009862
0.31 1.0827 0.00892050201188 0.0498074757828 0.0588660537024
0.34 1.2022 0.00954538707172 0.0664175849128 0.0748648074769
0.38 1.3482 0.00954771765068 0.0674273763961 0.0771813359882
0.41 1.5152 0.0092383914503 0.046694883268 0.0631644033659
0.44 1.6892 0.00903259987707 0.056077198035 0.0728909841395
0.46 1.8771 0.00924219406948 0.0560430356849 0.0762589038741
0.49 2.0922 0.00966014298481 0.0540434236287 0.079232776962
0.52 2.2824 0.00997588781643 0.0706996581482 0.0947913237982
0.55 2.5561 0.010812869636 0.0966973208017 0.119665293071
0.58 2.7516 0.011340154265 0.0904922145891 0.118019340447
0.61 2.9627 0.0117670767284 0.0864024068257 0.11916874363
0.65 3.1336 0.0120919996008 0.12511703939 0.152009756962
0.68 3.331 0.0124217041146 0.125285718527 0.155235362921
0.71 3.5514 0.0128579224678 0.125442751205 0.159225107067
0.73 3.8116 0.013401587694 0.104746157196 0.147970553414
0.76 4.1074 0.0146749011101 0.157216593518 0.195517631954
0.79 4.3388 0.0172087160512 0.251812668648 0.277540145723
0.82 4.6929 0.0239125966676 0.211653461395 0.247972304994
