Measurement E161M68

Experiment: g13
Year: 2006

Experiment comment:

Ran: 2006-2007
Spokesperson: Paul Mattione
Reaction: γn → π− p
Polarization: none
Quantity: dσ/dΩ
Eγ: 1.115 GeV
Publication:
P. T. Mattione et al. (CLAS Collaboration) Differential Cross Section Measurements for γn → π−p Above the First Nucleon Resonance Region // Phys. Rev. C 96, 035204 (2017) arXiv:1706.01963 [nucl-ex]

Measurement data
cos(θπ) dσ/dΩ, [μb] uncertainty syst. uncert. full uncertainty
-0.67 0.618 0.0120617459191 0.051506546044 0.0553980260254
-0.65 0.5585 0.0114181246314 0.0641924172306 0.0669872665566
-0.61 0.5408 0.00988263959391 0.0450282515168 0.0482595425916
-0.58 0.5342 0.00987633525062 0.0515626609284 0.0544037089852
-0.55 0.5451 0.00975153768844 0.0526037785022 0.0556556392755
-0.53 0.546 0.0094006006006 0.0448248670756 0.0482890369752
-0.49 0.6138 0.012533203125 0.0718145446231 0.074710480288
-0.46 0.6349 0.00966577146767 0.0850525300149 0.0873459133794
-0.43 0.6346 0.00854643709512 0.0541294597514 0.0574686851991
-0.41 0.6194 0.00754183336232 0.075524371891 0.077832994698
-0.38 0.5871 0.00697395833333 0.0342981618336 0.0385228346447
-0.34 0.5975 0.00705203862661 0.0320329322918 0.036506386908
-0.31 0.5999 0.0070238424694 0.0245135806639 0.030084485293
-0.28 0.6215 0.00710104024557 0.0402788434222 0.0442761093851
-0.26 0.6356 0.00739069767442 0.0411414339551 0.0450845232283
-0.22 0.5925 0.00683694301438 0.0336116975206 0.0377547536725
-0.2 0.5999 0.00691708595388 0.0356348694667 0.0399859859495
-0.17 0.5805 0.00658234341253 0.0386434050674 0.0422168130203
-0.14 0.5626 0.00656366666667 0.0312174355111 0.0355223512492
-0.1 0.5697 0.00675492520978 0.0332201894247 0.0373122600797
-0.07 0.5611 0.00674025133986 0.0300534359413 0.0345047847906
-0.04 0.5507 0.00652267343486 0.0445247653701 0.0476044780532
-0.02 0.5295 0.0059982421875 0.0372197674719 0.040384618541
0.02 0.5357 0.00568464209917 0.0279273135873 0.0319629605037
0.04 0.5541 0.00558130945719 0.0371834504147 0.0406709081783
0.07 0.5676 0.00547856492442 0.0268467004745 0.0314829568833
0.1 0.5926 0.00579155322862 0.0320814262651 0.0365591708029
0.14 0.6287 0.00610589300412 0.0310044846856 0.036167422935
0.17 0.6714 0.00621283158544 0.0362717620704 0.0412508604369
0.2 0.7186 0.0062171593367 0.0414361789959 0.0462948636306
0.23 0.7979 0.00663448096661 0.0331424751988 0.0402038103942
0.26 0.8899 0.00736397435897 0.0270142903227 0.0367840609732
0.28 0.992 0.00830125523013 0.0290366864777 0.0404958112717
0.31 1.0874 0.0092390071599 0.0581708754163 0.066147552878
0.34 1.1872 0.00955242259927 0.0394602486369 0.0518111557487
0.38 1.3534 0.00965898242652 0.0706427211996 0.0805088373445
0.41 1.4931 0.00924552285535 0.057157066992 0.0706668338102
0.44 1.6949 0.00924868792152 0.0717060093139 0.0861049990657
0.46 1.8903 0.00945929612318 0.0623869514951 0.0817491451844
0.49 2.045 0.0096702598261 0.0468116019262 0.0737404284932
0.52 2.2948 0.0104025385313 0.0801275682403 0.102099466621
0.55 2.5046 0.0109284823803 0.0853028034291 0.110067124579
0.58 2.6892 0.0114558128727 0.0916871002455 0.118343520999
0.61 2.9485 0.0120908512443 0.104200870036 0.132081015137
0.65 3.0961 0.0123121962727 0.125196045556 0.151553889216
0.68 3.3259 0.012746915054 0.135803078598 0.163913983501
0.71 3.5536 0.0131855115142 0.156947100279 0.185142513143
0.73 3.8242 0.0138349110642 0.10479067342 0.148854331176
0.76 4.0588 0.0149019960699 0.167940139672 0.204332795505
0.79 4.3393 0.0173303117587 0.220520067781 0.249555347293
0.82 4.6233 0.0237086879879 0.201107304974 0.239035563375
